Heat pipe used in electronical cooling

Views: 72     Author: Site Editor     Publish Time: 2022-02-11      Origin: Site

Winshare Heat Pipes assemblies have emerged as the most important tool available for the transfer of heat energy. How does the thermal engineer cope with conflicting demands for small package that incorporates suffcient cooling to insure high component relibility and long component life?

The thermal designs of equipment have become as important as the electronic designs. Overheating shortens component life, threatens specification compliance by decreasing performance. Of the carious means of transferring and dissipating this heat, the heat pipe is in many respects the most satisfactory.

The heat pipe is a self-contained device of very high thermal conductivity. Heat pipes are relatively small and lightweight, they transfer heat at a high rate over a considerable distance with extremely small temperature drop.

What is heat pipe and what are major variables associated with heat pipe performance?

The heat pipe is a sealed tube which enclose a capillary wick. The wick is saturated with liquid phase of working fluid.

The remaining volume of the pipe contains the vapor phase.In its longitudinal direction, the heat pipe contains an evaporator section and condenser section which are separated by an adiabatic section. As heat is applied externally at the evaporator end, the fluid in that section vaporizes.

The resulting difference in pressure drives vapor from the evaporator to the condenser section,where it condenses thus releasing the latent heat of vaporization.

The condensed fluid travels by capillary action along the wick back to the evaporator end. Then the whole cycle repeats. The heat pipe can therefore transport a large amount of heat with small unit size and weight.

Variables related to heat pipe performance:

Total heat carried from the input end to the output end in Watts.

Thermal gradient in heat pipe along its length.

3-Input and output thermal drop.

Gravity orientation.

Maximum storage or use temperature.

Operating temperature: Heat pipe cooling performance is function of it’s temperature. The higher the temperature the, the more conductive the unit and the lower the overall thermal drop.

A heat pipe is not damage when allowed to cool below it s temperature rating; it may cease to function but will resume normal activity when warmed again to within its operation limits. The maximum storage temperature range is always calculated for use under atmospheric pressure, and the range will be lower in a vacuum or at high altitude.

Custom design:

Winshare engineers can design and build custom heat pipes heat sink to solve any thermal problem.The cost on special heat pipes are comparable with those of standard models, since most of custom devices can be made largely from properly selected and assembled standard components.

Typical applications of heat pipes: Heat pipes, because of their lightweight, compact structure and their efficient, virtually isothermal operation, have found a wide variety of applications.

Heat pipe applications can be grouped into:


Temperature leveling and eliminating hot spots

Remote cooling (separation of heat source and heat sink)

Constant temperature maintenance

Temperature control
