The electric vehicle (EV) market is growing fast. EVs need high performance. This means long driving ranges and quick charging times. These two factors require high power density. High power density creates huge thermal management challenges. The battery packs and the power electronics (inverters) must be kept within a tight temperature range.
The cooling plate is a critical component. It has two main jobs. First, it must provide uniform temperature control across the cells. Second, it must offer high structural reliability to withstand road conditions.
We introduce Vacuum Brazing as a key manufacturing technique. It is a liquid-state joining process. It excels at creating complex internal structures. It is also superior at minimizing interface thermal resistance.
This article analyzes the role of vacuum brazing in the EV sector. We compare it with Friction Stir Welding (FSW). We detail the unique value of brazing. We explain its best application scenarios.
This section focuses on the fundamental principles of brazing. It explains how this process delivers crucial performance improvements for EV cold plates.
Vacuum brazing is a precise joining method. It is performed in a controlled vacuum furnace. This furnace environment is essential.
Preparation: The components (the base plate and fins) are assembled. A filler metal, the braze alloy, is placed between them. The braze alloy has a lower melting point than the parent material (usually aluminum).
Vacuum: The assembly enters the vacuum furnace. The vacuum prevents oxidation. This eliminates the need for corrosive chemical flux.
Bonding: The temperature rises. The braze alloy melts. It flows into the gaps between the fins and the base plate. It uses capillary action to fill the entire joint.
Solidification: The alloy cools down. It forms a perfect metallurgical bond between the components.
The key advantage is cleanliness. This process removes voids and flux residue. It ensures the thermal path is complete and robust.
The metallurgical bond provides significant thermal advantages.
Brazing achieves nearly 100% metal-to-metal contact. The filler metal fills all microscopic gaps. This ensures the lowest possible interface thermal resistance (Rinterface). This is vital for transferring heat quickly from the base to the cooling channels.
Brazing allows for the integration of complex internal structures. It can incorporate corrugated fins or specialized micro-channel geometries. These complex designs significantly increase the convective heat transfer surface area ($\text{A}_{\text{conv}}$). This boost in area directly improves the cold plate's thermal performance.
Choosing the right manufacturing process is a key engineering decision. We must compare the unique value of Vacuum Brazing against Friction Stir Welding (FSW).
FSW is a solid-state joining process. It is a widely accepted technique in the EV industry, particularly for aluminum.
High Strength: FSW produces a strong, defect-free weld seam. This is important for structural integrity.
No Filler Material: It does not use filler material. This reduces potential material incompatibility.
Cost-Effective for Scale: It is fast and scalable for large, simple parts.
FSW is best suited for large, flat, single-layer EV battery base plates. These applications prioritize structural reliability and economy of scale. They require simple, strong flow paths.
Vacuum brazing offers specialized capabilities that FSW cannot match. These capabilities are crucial for high-power components.
Inverter modules (using IGBT or SiC chips) have extreme heat flux density. They require the absolute lowest thermal resistance (Rth). Brazed cold plates (especially those made from Copper or hybrid Copper/Aluminum) are the best choice here.
Brazing can reliably join Copper and Aluminum components. This is nearly impossible with FSW or standard welding. This feature is vital for hybrid designs. These designs use a Copper base (for high thermal conductivity near the chip) and an Aluminum flow plate (for low weight and cost). Brazing provides the robust thermal path needed between the two dissimilar metals.
Brazing allows engineers to connect multiple layers of flow channels in one pass. This creates highly integrated, multi-functional cooling structures. This is used for cell-to-plate cooling where dual-sided heat removal is needed. This level of structural complexity is difficult to achieve with FSW's simple weld seams.
Brazing offers high performance. But it introduces specific design challenges in the EV application environment. Winshare Thermal specializes in managing these challenges.
The high performance of brazed cold plates comes from complex internal geometry.
Complex fins (like corrugated fins) dramatically increase heat transfer efficiency. However, they also cause a significant increase in pressure drop (DeltaP). High DeltaP increases pumping power consumption. The design must find the optimal trade-off point. Winshare uses advanced CFD (Computational Fluid Dynamics) simulation. This tool helps engineers analyze the flow path. It ensures maximum heat transfer within the client's available $\Delta\text{P}$ budget.
Complex brazed channels can suffer from uneven flow. Fluid prefers the path of least resistance. This leads to starved channels and hot spots. Winshare designs precise internal manifolds and flow dividers. This ensures every channel receives an equal flow rate. It guarantees consistent cooling efficiency across the entire surface.
The EV industry has strict quality standards (like TS16949). Brazing must meet these standards for mass production.
The brazing process is extremely sensitive to cleanliness. Any impurity or oil residue on the raw material will vaporize in the vacuum. This creates defects. It prevents the braze alloy from flowing correctly. Winshare employs rigorous, multi-stage cleaning processes. We ensure materials are pristine before they enter the furnace. This strict quality control guarantees defect-free braze joints.
When using Copper-Aluminum hybrid cold plates, galvanic corrosion is a risk. Brazing must use an appropriate, inert braze alloy. The design must also isolate the materials. This prevents the braze alloy itself from becoming a corrosion site. Proper material and coolant selection is vital. It ensures the long-term reliability required for a vehicle's 10-year life span.
The process selection for EV cooling plates is a fundamental engineering trade-off.
FSW is the dominant choice for large, light-weight, scalable battery base cooling. It offers robust structure and low cost at volume.
Vacuum Brazing is the critical choice for extreme performance, high structural integration, and mixed-material applications. This includes high-power inverters and high-density fast-charging batteries.
The trend in the EV market is clear. 800V architecture and ultra-fast charging are becoming standard. This drastically increases the thermal demands on cooling plates. The requirement for lower thermal resistance will soon outweigh simple structural strength in these high-power areas. Vacuum brazing will become increasingly essential for these high-power density components.
Winshare Thermal is a leader in advanced cooling manufacturing. We master both FSW and Vacuum Brazing technologies. We provide precise process selection based on your TDP, material preference, and cost requirements. Contact us to design a custom cooling solution that meets the demands of the 2025 EV market and beyond.
