What is a Composited heat sink?

A composite heat sink refers to a heat dissipation component that is formed through a specific process by combining two or more materials with different thermal and mechanical properties (such as metals with metals, metals with ceramics, metals with polymers, etc.).

The core design concept of a composite heat sink is "complementary advantages and coordinated performance" - it breaks through the performance limitations of a single material and achieves multi-dimensional optimization of "thermal conductivity efficiency, structural strength, lightweight, and cost control" through material combination. In particular, it addresses the pain points of traditional pure metal heat sinks (copper/aluminum) in terms of thermal expansion matching, weight control, or adaptability to extreme environments.
heatsink
10
99

Composited heat sink Product Categories

Why Choose Winshare?

Choosing Winshare means choosing an industry-leading thermal management expert. We not only provide excellent products, but also provide customized, high-performance and highly reliable all-round thermal management solutions. We are committed to protecting your critical applications with innovative technology, sophisticated processes and strict quality standards.

Winshare Composited heat sink Advantages and Features

Core Advantages
Professional R&D Team: Extensive experience collaborating with top global companies, proficient in CFD thermal simulation, structural mechanics, and fluid analysis.
Precise Performance Optimization: Utilizes advanced simulation tools and massive data to minimize gaps between simulation and real-world performance.
Trusted by Renowned Brands: Gained recognition from leading enterprises including Delta Electronics and Sungrow Power Supply.

Technical Features
Maximized Heat Dissipation Efficiency: High fin height-to-pitch ratio expands surface area, enhancing convective cooling (suitable for forced/natural convection systems).
Flexible Material & Structural Design: Supports material combinations (e.g., copper base + aluminum fins, aluminum base + copper fins) for balanced performance, weight, and cost; customizable base via extrusion, machining, or die casting for seamless integration.
Reliable Bonding Technologies: Options include high thermal conductivity epoxy bonding, precision brazing, soldering, or welding (brazing ensures minimal thermal resistance).
Versatile Assembly Configurations: Compatible with heat pipes/vapor chambers, zipper fins, and sheet metal (e.g., Al heat sink + heat pipe/Cu base, Al/Cu base + heat pipe + zipper fin).
Bonded-fin-heat-sink4_03
Service Capabilities
Comprehensive Customization: Tailored solutions for space-constrained or harsh operating environments, covering material selection to structural optimization.
Seamless Production Support: Efficient, flexible services from low-volume prototyping to large-scale mass production, accelerating time-to-market.

Winshare Composited heat sink Customization Solution

hx
Winshare is committed to providing customers with excellent customized thermal management solutions. We know that each project has its own unique needs and challenges, so we do not provide a "one-size-fits-all" product, but through a deep understanding of your specific application, we tailor the most optimized and efficient bonded fin heat sink.
Group 1321314558
In-depth communication and assessment of needs

We will discuss your requirements in detail to fully understand your heat source characteristics, heat load, available space limitations, operating environment conditions (such as temperature, airflow type and velocity), target temperature, and any special performance requirements for the heat sink, such as noise, weight, and lifespan. We will also confirm the connection method between the heat sink and the heat source to ensure optimal heat transfer efficiency.



Group 1321314557
Professional thermal design and simulation optimization

Our team of experienced thermal design engineers utilizes industry-leading computational fluid dynamics (CFD) and finite element analysis (FEA) software to accurately simulate the heat sink's thermal performance, internal airflow distribution, and pressure drop under various operating conditions. During the design phase, key parameters such as fin height, spacing, wave form, and material thickness are comprehensively considered. Multiple rounds of iterative optimization ensure that the design closely matches actual operating conditions. Calibration using big data improves the success rate of first-time designs.

03
Advanced materials and manufacturing process selection

Based on factors such as thermal conductivity, weight, cost, and corrosion resistance, we recommend and utilize high-quality materials such as pure copper (C1100) and aluminum alloys (A6061, A6063). Winshare boasts industry-leading manufacturing capabilities, enabling us to select the most suitable and efficient processes based on design complexity and volume requirements, including precision folding, vacuum brazing, reflow/spot welding, and high-precision CNC machining.


Group 1321314560
Prototyping and rigorous validation

Once the design is finalized, we will quickly produce high-precision prototypes. In Winshare's well-equipped thermal testing lab, we conduct comprehensive thermal performance tests (such as thermal resistance and temperature rise) and reliability tests (such as thermal cycling, vibration shock, and salt spray corrosion) to ensure that performance fully meets design specifications and your expectations. All test data is carefully recorded and shared with customers.


04
Mass production and lean quality control

Once the prototype is validated, we'll initiate efficient mass production. Winshare strictly adheres to the ISO 9001 quality management system, implementing meticulous management and strict quality control at every stage, from raw material procurement, production and processing to final product shipment. We utilize advanced automated production equipment and high-precision testing instruments to ensure high consistency, superior quality, and long-term reliability in every batch of products, minimizing your risk.

Group 1321314561
On-time delivery and perfect after-sales service

We are committed to on-time product delivery, professional packaging, and global logistics support to ensure your products reach you safely and intact. Winshare's professional support team will provide ongoing technical consultation and responsive after-sales service to ensure your cooling solution operates stably and efficiently throughout its lifecycle, providing you with solid support.



Customized Case (Example)

Regardless of the size of your project, Winshare can provide you with customized bonded fin heat sink solutions to help you achieve the best performance.
crop_1767759898729

New Energy Vehicle Electronic Control System

Challenges: High power density, tight installation space, severe vibration and temperature cycling.
Winshare solution: A copper-aluminum composite bonded fin heat sink is used. The copper substrate is used to quickly conduct the heat of the IGBT module, and the aluminum fins reduce the overall weight. High reliability is ensured through precision brazing process, and the fin spacing is optimized to adapt to high-efficiency heat dissipation under forced air cooling conditions.
crop_1767760510021

Large Energy Storage System Inverter

Challenge: Continuous high power output and long-term stable operation require strict restrictions on the size of the heat sink.
Winshare solution: Designing an oversized bonded fin heat sink maximizes the heat dissipation surface area by optimizing the fin height and density. Combined with internal heat pipe technology, it evenly disperses heat and ensures the temperature stability of the inverter under long-term full-load operation.


The Answers to Your Questions Are Here.

  • Q How to get a quote for Winshare Composited heat sink?

    A
    Please contact our sales representative through our official website or directly. In order to provide the most accurate quotation, please provide as much detailed information as possible, including: design drawings (if any), detailed technical requirements (such as target heat dissipation power, space dimensions, airflow conditions, ambient temperature, etc.) and expected purchase quantity. Our team will provide you with a professional quotation as soon as possible.


  • Q Are Composited heat sink reliable in harsh environments?

    A
    Winshare's Composited heat sink take all kinds of harsh working conditions into full consideration during design and manufacturing. We conduct multiple reliability tests (such as thermal shock, vibration, salt spray corrosion, etc.) to ensure that the product can maintain excellent stability and long-term reliability in harsh environments such as a wide temperature range, high humidity, vibration shock, etc.


  • Q Can Winshare provide thermal management consulting for our specific applications?

    A
    Of course! Our professional thermal design team has rich industry experience and can deeply analyze your specific application scenarios and challenges, and provide comprehensive and customized thermal management consulting and solution recommendations from conceptual design, thermal simulation, structural optimization to final product implementation.


  • Q How to evaluate the heat dissipation performance of Winshare Composited heat sink?

    A
    We use double protection: first, in the design stage, we use advanced CFD thermal simulation software to make accurate performance predictions; second, after the prototype is completed, we will conduct rigorous thermal resistance testing, wind resistance testing and other necessary performance verifications in our professional thermal conduction laboratory, and provide detailed test reports to ensure that the product performance fully meets your design requirements.


  • Q How long is the cycle for customizing Winshare Composited heat sink

    A
    The customization cycle depends on the complexity of the design, material selection and order quantity. Generally, it takes about 3-5 weeks from the final confirmation of the design plan to the delivery of prototype samples. The cycle of mass production will be confirmed separately according to the specific order quantity and schedule. We will provide a detailed project schedule.


  • Q What material combinations can be used for Winshare's Composited heat sink?

    A
    We offer a variety of flexible material combinations, including but not limited to: aluminum substrate + aluminum fins, aluminum substrate + copper fins, copper substrate + copper fins, and copper substrate + aluminum fins. We can provide the most optimized material recommendations based on your specific thermal performance, weight, and cost requirements.


  • Q What are the main advantages of Composited heat sink compared to extruded heat sinks?

    A
    Composited heat sink can achieve a higher fin height to pitch ratio (i.e., a higher aspect ratio), providing a larger heat dissipation surface area, and are particularly suitable for large-size and high-power heat dissipation requirements. At the same time, it far exceeds the extrusion process in terms of size, material combination (such as copper-aluminum composite) and design flexibility, and can meet more stringent high-power heat dissipation requirements.
